RFID Boards - Model: TLB-1x Lite Series

Supplier: Existco Pty Ltd

The TECTUS TLB-10 series of LF- OEM read /write reader boards are what you need, if multi-tag communication, size and price are important.

With its multiple interface options like RS232, RS485, USB and TTL, the TLB-10 series offers highest flexibility and covers multiple applications e.g. toggling signals with an external antenna.

Due to its integrated antenna and voltage regulator, the compact reader board is perfectly suited for a stress less design-in. Two LED indicators and one I/O are on board available.

Key Features of RFID Boards - Model: TLB-1x Lite Series:

Ready to use reader board by connecting power and communication interface, On board amplifiers for higher performance compare to TLM-10, On board demodulator to increase sensitivity compare TLM-10
Synchronization of multiple readers via SYNC, 3 / (2) free configurable I/O port, (RS485 with only 2 IO’s), No quartz or external clock needed, 5V input and 9..12VDC
Offline functionality macro programmable by the customer, Application specific firmware versions (ASF) available, Full customized firmware possible on volume demand
Signal amplitude measurement to measure the signal strength of the tag, Command timing at the air interface is adjustable by parameters, External antenna can be easy added and toggled with the internal one,
2 LED‘s are already board mounted and can be controlled via the IO‘s, Low power consumption

More Information on RFID Boards - Model: TLB-1x Lite Series >>

To contact Existco Pty Ltd about RFID Boards - Model: TLB-1x Lite Series use Get a quote.
