SANY Large Excavators | SY135C
SANY - Large Excavators | SY135C
PERFORMANCE YOU CAN RELY ON.
The SANY SY135C sets a new benchmark in the 13–15 tonne large excavator class, delivering an exceptional balance of power, control, and efficiency. Designed for precision and reliability in infrastructure, civil, and general construction, it combines a reinforced boom and arm, a heavy-duty undercarriage, and advanced load-sensing hydraulics to ensure smooth, consistent performance in every application.
Powered by the Isuzu 4JJ1X Stage V engine, the SY135C delivers superior fuel economy, low emissions, and consistent high torque output across diverse operating conditions. The robust dozer blade and stable track platform provide outstanding digging force and lifting stability, even in demanding terrain. Equipped with a broad range of standard and optional configurations, the SY135C is engineered to maximise versatility and productivity on any job site.
Key Features
- Rear camera
- 2 proportional auxiliary lines as standard
- High-resolution 7“ touch display
- Hydraulic quick-coupler line system
- Heavy-duty undercarriage
General Information
- Weight
14870 kg
- Standard bucket capacity
0.6 m³
- Transport length
7700 mm
- Transport width
2590 mm
- Height over cabin/ROPS
2820 mm
- Engine
ISUZU GJ-4JJ1XKSC
- Rated Power
73 kW
- Engine Revolutions
2000 rpm
- Emission Stage
III
- Max. digging depth
5500 mm
- Max. digging reach
8,270 mm
- Min. Swing radius
2,410 mm
- Bucket digging force (ISO)
92.7 kN
- Arm digging force (ISO)
67 kN
- Max. oilflow
2x110 l/min
To contact Putzmeister Oceania Pty Ltd about SANY Large Excavators | SY135C use Get a quote.
The SANY SY135C sets a new benchmark in the 13–15 tonne large excavator class, delivering an exceptional balance of power, control, and efficiency. Designed for precision and reliability in infrastructure, civil, and general construction, it combines a reinforced boom and arm, a heavy-duty undercarriage, and advanced load-sensing hydraulics to ensure smooth, consistent performance in every application.
Powered by the Isuzu 4JJ1X Stage V engine, the SY135C delivers superior fuel economy, low emissions, and consistent high torque output across diverse operating conditions. The robust dozer blade and stable track platform provide outstanding digging force and lifting stability, even in demanding terrain. Equipped with a broad range of standard and optional configurations, the SY135C is engineered to maximise versatility and productivity on any job site.
Key Features
- Rear camera
- 2 proportional auxiliary lines as standard
- High-resolution 7“ touch display
- Hydraulic quick-coupler line system
- Heavy-duty undercarriage
General Information
- Weight
14870 kg
- Standard bucket capacity
0.6 m³
- Transport length
7700 mm
- Transport width
2590 mm
- Height over cabin/ROPS
2820 mm
- Engine
ISUZU GJ-4JJ1XKSC
- Rated Power
73 kW
- Engine Revolutions
2000 rpm
- Emission Stage
III
- Max. digging depth
5500 mm
- Max. digging reach
8,270 mm
- Min. Swing radius
2,410 mm
- Bucket digging force (ISO)
92.7 kN
- Arm digging force (ISO)
67 kN
- Max. oilflow
2x110 l/min
To contact Putzmeister Oceania Pty Ltd about SANY Large Excavators | SY135C use Get a quote.
