Weld-Mart is a proud supplier of Alfra Mag Drills. Made in Germany to exacting standards and specifications, Alfra has a mag drill to suit the most demanding drilling applications.

Good Reasons To Decide on a ALFRA ROTABEST Mag Drill:
• Powerful Motors with high torques and a range from 900 to 1800W, ergonomic design, perfect technology.
• Magnet feet with 3 coils instead of 2 and with the new M.P.I. magnet system (Magnetic Power Increase). Electronic increase of magnetic adhesion at the start of the drilling operation, when strongest adhesion is required (for higher protection of user and tool).
• Pressed-in brass rings for an improved protection of the magnet coils.
• Motor height continuously adjustable on the slide for maximum stroke enlargement, when using twist drills, drill chucks and tapping attachments.
• Rota-Quick – quick change arbor – problem-free cutter changing. An advantage compared with other quick change arbors: fits every common cutter with Weldon shank.
• Durable keyboard with flat cable. Panel angled directly in sight of the user. Easy to reach keyboard, even in narrow U-beams and H- beams.
• Newly designed gear-housing with integrated motor support. With built-in height adjustment by means of clamping jaws – there is simply no better fixing device.

TO DETERMINE IF WE CAN ASSIST WITH YOUR SPECIFIC REQUIREMENTS PLEASE CONTACT US.

NEW PICCOLO - Accepts cutters up to Ø40mm
• 12mm – 40mm Ø Core Drill Capacity
• Most compact drill on the market
• Solid brass guides
• 106mm – 191mm height adjustment
• Durable keyboard
• 1100 watt motor
• 400 R.P.M.
• 8000N magnetic adhesion
• 50mm core drill cutting depth
• 132mm stroke
• Integrated cooling system with coolant unit
• Safety belt
• Huge Slide adjustment fits standard length drill bits.
• Very Compact and light - less than 10kg.

NEW MINI. Accepts cutters up to Ø50mm
• Solid Brass Guides
• 114mm - 229mm Height Adjustment
• 1200 Watt Motor
• Two Speed Oil Bath Gearbox 250/450 R.P.M.
• 12000N Magnetic Adhesion
• 50mm Core Drill Cutting Depth
• 140mm Stroke
• Integrated Coolant System
• Safety Belt

NEW GEN 50 RQ. Accepts cutters up to Ø50mm
LATEST TECHNOLOGY IN MAGNETIC DRILLS
• 12mm – 50mm Ø Core Drill Capacity
• Solid brass guides
• 160mm – 260mm height adjustment
• New 3 coil magnetic power increase magnet
• New rota quick change system
• Durable keyboard
• Powerful 1200 watt motor
• 2 speed gearbox 250 / 450 RPM
• 16000N magnetic adhesion
• 50mm core drill cutting depth
• 170mm stroke
• Accepts tapping chuck
• Integrated cooling system with coolant bottle
• Safety belt
• Only 16kg
ALL CONTAINED IN A PLASTIC TRANSPORT CASE

JUNIOR TAPER. Accepts cutters up to Ø80mm
• Up to 80mm Ø core drill capacity
• Solid brass guides
• 226mm – 286mm height adjustment
• New 3 coil magnetic power increase magnet
• Durable keyboard
• No.3 Morse taper
• Powerful 1800 watt motor
• Gearbox with clutch
• 4 speed gearbox 110, 175, 245, 385 RPM
• 20000N magnetic adhesion
• Adjustable magnet foot 30˚ t o left + right
• 200mm stroke
• 110mm core drilling depth (with AMK 3L)
• Safety belt
• Only 22kg
ALL CONTAINED IN A PLASTIC TRANSPORT CASE
• Coolant unit, tool holder and cutter are optional extras

MASTER TAPER. Accepts cutters up to and over Ø100mm
KING OF MAGNETIC DRILLS
• Over 100mm Ø core drill capacity
• Solid brass guides
• 295mm – 400mm height adjustment
• New 3 coil magnetic power increase magnet
• Durable keyboard
• No.3 morse taper
• Powerful 1800 watt motor
• Gearbox with clutch
• 4 speed gearbox 110, 175, 245, 385 RPM
• 20000N magnetic adhesion
• Adjustable magnet foot 30˚ to left + right
• 245mm stroke
• 110mm core grill depth ( with AMK 3L )
• 35mm twist drill capacity
• 30mm tapping capacity
• Safety belt
• Only 28kg
ALL CONTAINED IN QUALITY TRANSPORT CASE
• Coolant unit, toolholder & cutter are optional extras

V32 COMPACT. Accepts cutters up to Ø32mm
• Cutting Depth of 25mm
• Automatic Cooling through the Spindle
• This horizontal metal core drilling machine is developed for the tightest spaces.
• Perfect to use where regular metal core drilling machines have to quit due to their height
• Gear ratchet lever switchable from right to left hand operation.
• The total height is just 227 mm and can even be reduced to 185 mm by removing the handle.
Comes with:
Coolant Unit With Hose And Nipple
• Transport Case
• Allen Key For Welden Arbor
• Safety Belt
• HSS Co Cutter
• Ejector Pin
• Operation Manual
