Flush-Mount Moisture Sensor for Concrete Mixers & Belts – Hydro-Mix

Supplier: Allegiant Milling & Processing Solutions

1/3

A flush-mounted moisture sensor fitted in the floor or wall of concrete mixers, or over a belt conveyor, to measure moisture in concrete, sand, stone and other aggregates in real time. Supplied and supported in Australia by Allegiant.

Flush-mount sensor for concrete

Brand: Hydronix

Where it's used

Materials: concrete, sand, stone and other aggregates
Planetary mixers: in the mixer floor
Single/twin shaft mixers: about 30° from vertical on the blade upstroke
Turbo mixers: in the base, two-thirds out from the centre
Belt conveyors: in a Hydro-Skid riding on the material

What it measures

Moisture content of material passing the sensor face, plus material temperature.

Key features

Flush mount – sits level with the mixer floor or wall
Hard-wearing for abrasive materials
Selectable measurement modes
Adjustable signal filtering via Hydro-Com
Internal temperature compensation
Fixing plates in mild steel or 316 stainless steel; ceramic disc and protection ring kits

Specifications

Specification	Value
Supply voltage	15–30 V DC (several sensors can share one supply)
Measurement rate	25 readings per second
Outputs	2 × analogue, RS485 with Modbus, configurable digital inputs/outputs
Accuracy (once calibrated, as published by Hydronix)	0.2% for aggregates, 0.1% in a mixer, 0.5% for other materials
Maximum cable run	100 m (screened 6-pair, 22 AWG / 0.35 mm² cable recommended, e.g. Belden 8306 or Alpha 6373)

Why buy from Allegiant

Allegiant supplies, installs and supports Hydronix moisture measurement across Australia and the Pacific, alongside complete grain processing and sorting systems. Tell us your material, process and installation point and we'll recommend the right sensor and provide a quote.
