Meyer - Grain, Pulse, Nut, Fruit & Vegetable Belt Colour Sorter – KS Series

Supplier: Allegiant Milling & Processing Solutions

Grain, Pulse, Nut, Fruit & Vegetable Belt Colour Sorter – KS Series

1/3

Double-layer belt colour sorter for grains, pulses, nuts, fruit and vegetables – including large, fragile or wet product – that re-sorts rejects to cut good-product loss. Supplied, installed and supported in Australia by Allegiant.

Belt sorter for grains, nuts & produce

What it sorts

Grains & pulses

Grains
Pulses

Nuts

Nuts

Fruit & vegetables

Fruit
Vegetables

Irregular, large, fragile and high-moisture products are a particular focus of this belt design.

What it removes

Discoloured, damaged, mouldy and insect-damaged pieces
Some foreign material, including glass, plastic and sand

Key features

Double-layer re-sort – a second sorting stage re-checks material to improve final accuracy while limiting product loss.
Belt design suited to irregular, large, fragile and high-moisture agricultural products.
Modular construction intended for long service life.
AI defect recognition – deep-learning software classifies each particle by colour and shape against a library of product models; Meyer states defects down to 1–2 pixels can be picked up.
High-speed imaging – Meyer quotes 50,000 scans per second and detection of objects as small as 0.0025 mm².
Maglev 3.0 ejectors – non-contact air ejectors rated by Meyer at over 1,200 Hz, designed to reject only what needs rejecting and keep good-product loss down.
Multispectral vision options – Meyer's vision platform covers visible, infrared, UV and X-ray identification; confirm the configuration for your product with Allegiant.
Full RGB lighting with an adjustable background colour to improve contrast between good product and defects.
Sniper System – 3D reconstruction locates the centre of a contaminant so the air blast is aimed precisely.
Remote support – remote monitoring, start-up, settings backup and diagnostics.
Simple operator interface, with operator training provided.

Specifications

Model	Sorter code	Power (kW)	Voltage	Air pressure (MPa)	Air consumption (m³/min)	Dimensions L × W × H (mm)	Weight (kg)
240KS5	6SXZ-240KS5	7.8	180–240 V, 50 Hz	0.6–0.8	6.0	3560 × 2200 × 2615	1650
480KS5	6SXZ-480KS5	12.6	180–240 V, 50 Hz	0.6–0.8	9.0	3560 × 2800 × 2615	2250

Why buy from Allegiant

Allegiant supplies, installs and supports Meyer optical sorters across Australia and the Pacific, from plant design through to commissioning and optimisation. Send us details of your product and throughput and we'll recommend the right configuration and provide a quote.
