Sand & Aggregate Moisture Probe for Bins & Conveyors – Hydro-Probe

Supplier: Allegiant Milling & Processing Solutions

1/2

A tough moisture probe that mounts in or under sand and aggregate bins, or over a belt conveyor, so concrete and asphalt plants can correct batch water for wet sand and stone. Supplied and supported in Australia by Allegiant.

Moisture probe for sand & aggregate

Brand: Hydronix

Where it's used

Materials: sand, stone, recycled asphalt pavement (RAP) and other aggregates
Bins: in the bin neck, in the bin side, below the bin gate, angled into narrow-neck bins, or in wide bins with an extension sleeve
Belt conveyors
Vibratory feeders (on application)
Processes: batching/weighing, conveying, water/chemical addition

What it measures

Moisture content of aggregate flowing past the probe, plus material temperature.

Key features

Hard-wearing design for abrasive materials
Shape compacts the material at the sensor face for steadier readings
Digital measurement with a linear output
Adjustable signal filtering via Hydro-Com
Internal temperature compensation
Configure remotely via Hydro-Com, Hydro-View or Hydro-Hub

Specifications

Specification	Value
Supply voltage	15–30 V DC (several sensors can share one supply)
Measurement rate	25 readings per second
Outputs	2 × analogue, RS485 with Modbus, configurable digital inputs/outputs
Accuracy (once calibrated, as published by Hydronix)	0.2% for aggregates, 0.1% in a mixer, 0.5% for other materials
Maximum cable run	100 m (screened 6-pair, 22 AWG / 0.35 mm² cable recommended, e.g. Belden 8306 or Alpha 6373)

Why buy from Allegiant

Allegiant supplies, installs and supports Hydronix moisture measurement across Australia and the Pacific, alongside complete grain processing and sorting systems. Tell us your material, process and installation point and we'll recommend the right sensor and provide a quote.

Where it's used

Materials: sand, stone, recycled asphalt pavement (RAP) and other aggregates
Bins: in the bin neck, in the bin side, below the bin gate, angled into narrow-neck bins, or in wide bins with an extension sleeve
Belt conveyors
Vibratory feeders (on application)
Processes: batching/weighing, conveying, water/chemical addition

What it measures

Moisture content of aggregate flowing past the probe, plus material temperature.

Key features

Hard-wearing design for abrasive materials
Shape compacts the material at the sensor face for steadier readings
Digital measurement with a linear output
Adjustable signal filtering via Hydro-Com
Internal temperature compensation
Configure remotely via Hydro-Com, Hydro-View or Hydro-Hub

Specifications

Specification	Value
Supply voltage	15–30 V DC (several sensors can share one supply)
Measurement rate	25 readings per second
Outputs	2 × analogue, RS485 with Modbus, configurable digital inputs/outputs
Accuracy (once calibrated, as published by Hydronix)	0.2% for aggregates, 0.1% in a mixer, 0.5% for other materials
Maximum cable run	100 m (screened 6-pair, 22 AWG / 0.35 mm² cable recommended, e.g. Belden 8306 or Alpha 6373)
