The WEINIG SOLID PROFILE P 700 planing machine / moulder features Comfort Set wrench-free adjustments, very short setup times and a standard spindle speed of 7,000 rpm.

Very short setup times

Specification	Value
Model	SOLID PROFILE P 700
Standard spindle speed	7,000 rpm
Optional spindle speed	8,000 rpm
Production increase compared to conventional moulders	up to 15%

Comfort Set operating concept provides quick, accurate, error-free, wrench-free adjustments for pressure and guiding elements.
Improved ease of operation, very short setup times and a high degree of flexibility for four-sided processing.
Innovative machine technology, high production accuracy, high level of work safety and modular design.
Made in Germany.
Standard spindle speed increases linear production without sacrificing high surface quality; the optional higher speed offers a further production increase.

PowerLock: tooling system supporting very short retooling times, including switching to glazing bead profiling.
PowerCom Plus: networked management and work organisation solution for the SOLID PROFILE P 700, combining high performance with simple operation.
Pressure roller moving with the left spindle: overhead pressure roller opposite the left spindle moves with it to support workpiece guidance.

Profiled mouldings: profiling mouldings of all types with high profile precision, excellent surface quality and regular cuttermarks. Solid machine bases, precise machine tables, a right-angle fence, high true-running-accuracy spindles, a strong feed system and corresponding pressure elements provide smooth transportation in a defined position.
Window production: a special window package supports four-sided planing of window scantlings, removal of the blank glazing bead and glazing bead profiling. Push-button selection switches between planing alone and planing with glazing bead removal. Safety prompts prevent adjustment while a workpiece is in the machine and prevent collisions between the saw blade and contact pressure elements. The system also enables connection to a cross-cut saw and processing centre.

Specification	Value
Model	SOLID PROFILE P 700
Standard spindle speed	7,000 rpm
Optional spindle speed	8,000 rpm
Production increase compared to conventional moulders	up to 15%

Comfort Set operating concept provides quick, accurate, error-free, wrench-free adjustments for pressure and guiding elements.
Improved ease of operation, very short setup times and a high degree of flexibility for four-sided processing.
Innovative machine technology, high production accuracy, high level of work safety and modular design.
Made in Germany.
Standard spindle speed increases linear production without sacrificing high surface quality; the optional higher speed offers a further production increase.

PowerLock: tooling system supporting very short retooling times, including switching to glazing bead profiling.
PowerCom Plus: networked management and work organisation solution for the SOLID PROFILE P 700, combining high performance with simple operation.
Pressure roller moving with the left spindle: overhead pressure roller opposite the left spindle moves with it to support workpiece guidance.

Profiled mouldings: profiling mouldings of all types with high profile precision, excellent surface quality and regular cuttermarks. Solid machine bases, precise machine tables, a right-angle fence, high true-running-accuracy spindles, a strong feed system and corresponding pressure elements provide smooth transportation in a defined position.
Window production: a special window package supports four-sided planing of window scantlings, removal of the blank glazing bead and glazing bead profiling. Push-button selection switches between planing alone and planing with glazing bead removal. Safety prompts prevent adjustment while a workpiece is in the machine and prevent collisions between the saw blade and contact pressure elements. The system also enables connection to a cross-cut saw and processing centre.
